SMT RX-7R/8 P8 JUKI Pick and plac machine HF1005R nozzle EZA1923877A Components 0603 nozzle
JUKI nozzle part number:
- E35017210A0 JUKI NOZZLE 101 ASSY Ø 1.0x0.4
- E35027210A0 JUKI NOZZLE 102 ASSY Ø 1.5x1.0
- E35037210A0 JUKI NOZZLE 103 ASSY Ø3.0x1.7
- E35047210A0 JUKI NOZZLE 104 ASSY Ø 4.0x3.2
- E35057210A0 JUKI NOZZLE 105 ASSY Ø 6.5x5.0
- E35067210A0 JUKI NOZZLE 106 ASSY Ø 9.0x8.0
- E35517210A0 JUKI NOZZLE 201 ASSY Ø 3.5x1.0
- E35527210A0 JUKI NOZZLE 202 ASSY Ø 5.5x3.2
- E35537210A0 JUKI NOZZLE 203 ASSY Ø 8.5x5.0
- E35547210A0 JUKI NOZZLE 204 ASSY Ø 9.0x8.0
- E3600729000 JUKI NOZZLE 500 Ø 0.7x0.4
- E36017290A0 JUKI NOZZLE 500 Ø 0.7x0.4
- E36037290A0 JUKI NOZZLE 500 Ø 1.6x1.0
- E36047290A0 JUKI NOZZLE 500 Ø 3.5x1.7
- E36057290A0 JUKI NOZZLE 500 Ø 5.0x3.2
- E36067290A0 JUKI NOZZLE 500 Ø 8.5x5.0
- E36077290A0 JUKI NOZZLE 500 Ø 9.0x8.0
- E36087290A0/40011046 JUKI NOZZLE 500 ASSY Ø1.0 X 0.5
- E36007290A0/40001339 JUKI NOZZLE 501 ASSY Ø 0.7x0.4
- E36017290A0/40001340 JUKI NOZZLE 502 ASSY Ø 0.7x0.4
- E36027290A0/40001341 JUKI NOZZLE 503 ASSY Ø1.0x0.6
- E36037290A0/40001342 JUKI NOZZLE 504 ASSY Ø1.5/1.0
- E36047290A0/40001343 JUKI NOZZLE 505 ASSY 3.5/1.7
- E36057290A0/40001344 JUKI NOZZLE 506 ASSY Ø5.0/3.2
- E36067290A0/40001345 JUKI NOZZLE 507 ASSY Ø8.5/5.0
- E36077290A0/40001346 JUKI NOZZLE 508 ASSY Ø8.5 /5.0
- E36077290A0/40025165 JUKI NOZZLE 509 ASSY Ø0.1/0.4
- E36157290A0 JUKI NOZZLE 510 ASSY Ø1.5/0.6
- E36167290A0 JUKI NOZZLE 511 ASSY Ø2.0/1.2
- E40017210A0 JUKI PICK UP NOZZLE
- E40027210A0 JUKI PICK UP NOZZLE
- E40057210A0 JUKI PICK UP NOZZLE
- E40067210A0 JUKI PICK UP NOZZLE
- E40077210A0 JUKI PICK UP NOZZLE
- E40087210A0 JUKI PICK UP NOZZLE
- E40097210A0 JUKI PICK UP NOZZLE
- E40107210A0 JUKI PICK UP NOZZLE
- E40117210A0 JUKI PICK UP NOZZLE
- E40127210A0 JUKI PICK UP NOZZLE
- E40137210A0 JUKI PICK UP NOZZLE
- E40147210A0 JUKI PICK UP NOZZLE
- E40167210A0 JUKI PICK UP NOZZLE
- E40177210A0 JUKI PICK UP NOZZLE
- E40187210A0 JUKI PICK UP NOZZLE
- E40207210A0 JUKI PICK UP NOZZLE
- E40217210A0 JUKI PICK UP NOZZLE
- E40227210A0 JUKI PICK UP NOZZLE
- E40237210A0 JUKI PICK UP NOZZLE
- E40247210A0 JUKI PICK UP NOZZLE
- E40257210A0 JUKI PICK UP NOZZLE
| JUKI P16/P16S Placing Head Nozzle, Reflect Square Nozzle |
| Machine | Nozzle | Model | Outer Diameter | Inner Diameter | Components |
|---|
| RX-7/RX-7R | 501 | HF0402R(C) | 0.4x0.3mm | 0.08mm(X) | 0402 |
| RX-7/RX-7R | 502 | HF0603R(C) | 0.6x0.3mm | 0.2mm | 0603 |
| RX-7/RX-7R | 503 | HF1005R(C) | 1.0x0.5mm | 0.4mm | 1005 |
| RX-7/RX-7R | 512 | HF1608R | 1.6x0.8mm | 0.7mm | 1608 |
| RX-7/RX-7R | 521 | HF3008R | 3.0x0.8mm | 1.6x0.4mm | LED |
| RX-7/RX-7R | 524 | HF3216R | 3.2x1.6mm | 1.2mm | 3216 |
